2-fixed panel + 2-door hinged front shower screen GLASS
📐 Ver tipos de soporte
Front shower screen with two 8mm fixed panels plus two 6mm swing doors with central entry and brass hinge, with magnetic closure. Tempered glass and aluminum profiles. Modern minimalist design without bottom profiles. Sizes to choose from.
Immediate delivery.
TYPE OF PROFILES
Profiles in polished silver aluminum.
ADJUSTMENT AND COMPENSATION PROFILES
The vertical profiles of the shower screen allow for adjustment of the screen and enable us to adapt it correctly to the conditions of the installation, compensating for any unevenness that may exist in the walls and adjusting to the necessary light opening.
Specifically, the Glass model's profiles allow for compensation from 1.5 cm up to 6 cm (depending on the chosen COMBI), which will allow us to overcome any discrepancies that may exist in the walls.
The Glass model is available in stock in established standard sizes and with ranges that allow us to adapt to the opening (see Glass model tables in the catalog). These ranges (minimum and maximum dimensions) will be achieved with the extension system retracted or fully extended.
GLASS AND DECORATIONS
GME only works with tempered glass screens. Tempered glass is a type of safety glass, processed with thermal or chemical treatments to increase its strength compared to normal glass. When tempered glass breaks, it shatters into many small pieces instead of splintering into large jagged fragments. These tiny pieces are less likely to cause injury.
This shower screen has 6 mm thick tempered safety glass on the doors and 8 mm on the fixed panels.
The Glass shower screen is available with transparent glass, another decoration option is our adhesive vinyls (delivery time 7 days).
LIFTING ON TURNING
This shower screen is equipped with a lifting system when the swing leaf is turned, integrated into the vertical profile, whereby the door lifts as we open it.
OPENING
The opening system is by means of swing leaves that allow a 90º turn outwards from the shower tray.
CLOSURE SYSTEM
The shower screen closure system is magnetic, which provides great convenience and watertightness when closing the screen.
WATERTIGHTNESS
At the bottom of each swing leaf, a rubber water deflector will be inserted, and a 0.5x0.5 cm aluminum metallic water deflector will be installed on the tray.
| ANTI-LIME TREATMENT | Yes |
| GLASS THICKNESS (mm) | 8/6 |
| HEIGHT (cm) | 195 |
| WARRANTY (years) | 3 |
| REVERSIBLE | Yes |
| QUALITY STANDARD | UNE-EN 14428:2005 + A1:2008 |
| LEAF RELEASE BUTTON | No |
| SOFT-CLOSE MECHANISM | No |
| OPENING (cm) | 90 |
| CATALOG REFERENCE | GL20505020G |
| ASSEMBLY INSTRUCTIONS | Download assembly instructions |
| PACKAGES | 6 |
