Corner shower screen hinged door + fixed panel + fixed side panel SPAZIO
Transparent shower screen with in-line fixed panel plus folding-sliding door plus fixed side panel, framed in polished chrome aluminum with 6mm tempered glass and anti-limescale treatment. 4 adjustable double rollers to maximize available space. Immediate delivery.
FRAME TYPE
Polished silver chrome and matte black aluminum profiles
ADJUSTMENT PROFILES
The Spazio model is in stock in pre-established standard sizes with ranges that allow us to adapt to the opening (see Spazio model tables in the catalog). These ranges are achieved by adapting the side profile to the required measurement. Therefore, during installation it will be necessary to cut the upper guide to adapt it to our opening; a hacksaw for steel will suffice.
GLASS AND DECORATIONS
GME only works with tempered glass screens. Tempered glass is a type of safety glass, processed with thermal or chemical treatments to increase its strength compared to normal glass. When tempered glass breaks, it shatters into many small pieces instead of splintering into large, jagged fragments. These tiny pieces are less likely to cause injuries.
This shower screen has 6 mm thick tempered safety glass.
The screen can be chosen with transparent glass.
Another decoration option is our adhesive vinyls (delivery time 7 days).
OPENING
The opening system is via 1 pivot door, which is equipped with rollers that slide along the upper and lower guides.
CLOSING SYSTEM
The closing system for the Spazio front with 1 pivot door is via a bubble gasket, which is inserted into the door and closes by entering the vertical profile.
The closing system for the front + fixed side panel format is via magnetic closure.
WATER-TIGHTNESS
The shower screen has vertical water deflector seals to guarantee water-tightness in the door opening.
The shower screen has an upper and lower profile, which guarantees perfect water-tightness.
| ANTI-CALC TREATMENT | Yes |
| GLASS THICKNESS (mm) | 6 |
| HEIGHT (cm) | 195 |
| WARRANTY (years) | 3 |
| REVERSIBLE | Yes |
| QUALITY STANDARD | UNE-EN 14428:2005 + A1:2008 |
| LEAF RELEASE BUTTON | No |
| SOFT-CLOSE SYSTEM | No |
| OPENING (cm) | 49 |
| CATALOG REFERENCE | 1200+1260+1263 |
| ASSEMBLY INSTRUCTIONS | Download assembly instructions |
| PACKAGES | 3 |
